UV-C Germicidal Lamp T5 G5/G13

UV-C germicidal lamps T5 G5/G13 from GMY Manufacturing,We offer equipment manufacturers and purification companies the state-of-the-art UV-C disinfection solutions needed to remain competitive.
Availability:
Inquire


Type

Power   consumption

Size

Base

Wavelength

Irradiance   @ 1m

av.life

UVCH4D15X135-G5

4W

15*135mm

G5

253.7nm

8uW/cm2

8000h

UVCH6D15X212-G5

6W

15*212mm

G5

253.7nm

16uW/cm2

8000h

UVCH8D15X288-G5

8W

15*288mm

G5

253.7nm

22uW/cm2

8000h

UVCH10D15X331-G5

10W

15*331mm

G5

253.7nm

28uW/cm2

8000h

UVCH15D15X437-G5

15W

15*437mm

G5

253.7nm

40uW/cm2

8000h

UVCH20D15X589-G5

20W

15*589mm

G5

253.7nm

70uW/cm2

8000h

UVCH30D15X894-G5

30W

15*894mm

G5

253.7nm

100uW/cm2

8000h

UVCH40D15X1198-G5

40W

15*1198mm

G5

253.7nm

135uW/cm2

8000h



UVCH4D15x135-G5 A3 specification.pdf

UVCH6D15x212-G5 A3 specification.pdf

UVCH8D15x288-G5 A1 specification.pdf

UVCH10D15x331-G5 A0 specification.pdf

UVCH15D15x437-G5 A0 specification.pdf

UVCH20D15x589-G5 A0 specification.pdf

UVCH30D15x894-G5 A0 specification.pdf

UVCH40D15x1198-G5 A0 specification.pdf


   Q      What is germicidal UVC？


   A       Germicidal UV (GUV) refers to using ultraviolet radiant energy to inactivate bacteria, mold spores, fungi or viruses. Wavelengths in the photobiological ultraviolet spectral band known as the “UV-C,” from 200 to 280 nanometers (nm), have been shown to be the most effective for disinfection, although longer, less energetic UV can also disinfect if applied in much greater doses.




   Q      Can UV-C kill viruses as well as bacteria?


   A       Yes, UV-C kills living bacteria and inactivate viruses. It can inactivate the SARS-CoV-2 virus, responsible for COVID-19 if illuminated by UV-C at the effective dose level





   Q      What is the applications for UV light？


   A       The UV lamp can be used in air, surface and water disinfection.






   Q      Do we need a ballast for UV light？


   A       Yes, a ballast is needed. the ballast provides a high voltage charge to ‘strike’ or ‘ionize’ the mercury. Then, once the mercury is ionized, the ballast reduces the voltage and amperage required to keep the

mercury ionized and emit a stable stream of UV light.
