172nm Excimer Irradiation Solution

GMY's 172nm excimer lamps are expertly crafted for applications in industrial production and scientific experimentation. Utilizing precise irradiation technology with high-energy vacuum ultraviolet (VUV) light, these lamps elevate process precision and manufacturing efficiency, fostering significant advancements in both innovation and efficiency.

Feature Highlights

uv curing lamp， uv light curing lamp， curing lamp ，uv excimer lamp

High Photon Energy Output

The 172nm excimer lamps deliver

high-energy photons.

excimer uv lamp， uv excimer lamp ，curing light ，curing uv light

Advanced Manufacturing Light Sources

Suitable for photocleaning, photocuring, photomodification, and TOC degradation

in the advanced manufacturing industry.

uv light curing ， light cleaning ，uv light cleaning ，uv light cleaner

Low-Temperature Radiation

Ensures a low-temperature working

environment, safeguarding delicate

materials against heat damage.

preparation of pure water ，uv cleaning light ，uv light cleaning machine ，far uvc excimer lamp

Rapid On/Off Switching

Features quick start and shut-off,

improving production efficiency

and minimizing energy use.

Eco-Friendly, Mercury-Free Design

Complies with environmental standards and protects the health of workers.

Simple Integration

Easy to integrate and implement, accommodating the needs of diverse

equipment.

Applications

uv curing lamp，uv light curing lamp，curing light ，curing uv light， uv light curing ，curing lamp uv，

Photocuring

Rapid curing of materials suitable for various industrial production processes.

light cleaning ，uv light cleaning， uv light cleaner，uv cleaning light， uv light cleaning machine

Photocleaning

Effective removal of organic contaminants from surfaces, enhancing product quality.

preparation of pure water，excimer lamp， excimer uv lamp ，uv excimer lamp，far uvc excimer lamp ，172nm excimer lamp， excimer lampen

Photomodification

The 172nm excimer lamps effectively alter the surface properties of materials to enhance performance.

excimer uv lamps ，lampe excimer，what is toc

Pure Water Preparation and TOC Degradation:

Efficient degradation of organic pollutants to achieve ppb-level purity in water quality.

What is a 172nm Excimer Lamp?

A 172nm excimer lamp produces VUV light at a precise wavelength through plasma discharge caused by the excitation of rare gases or their halides under high-energy electron impact. With its high energy and strong penetrating power, this light is suitable for a wide range of precision industrial applications.

172nm Excimer Lamps - Photocleaning

GMY's 172nm UV light cleaning technology is based on the principle of photochemical oxidation. By irradiating the organic material's surface with UV light, it generates free radicals, oxidizing organics into water and carbon dioxide, effectively removing surface contaminants.

172nm Excimer Lamps - Photocuring

GMY's 172nm excimer light curing technology harnesses high-energy 172nm UV light for rapid material curing with precise surface control. Compared to traditional UV curing, it shortens curing time and enhances surface modification effects.

172nm Excimer Lamp - TOC Removal

GMY provides innovative 172nm excimer lamp technology for the efficient degradation and reduction of total organic carbon (TOC) in water. By generating free radicals, our UV light systems oxidize organic matter into CO₂ and H₂O molecules. This advanced technology is particularly suitable for ultra-pure water production.

172nm Photomodification Module

GMY 172nm Photomodification Module, designed specifically for dental implant activation hydrophilic devices, is mainly used for surface modification of materials in a vacuum environment. This module effectively activates the hydrophilicity of the implant surface through 172nm excimer photocatalytic technology and removes hydrocarbons from the titanium metal surface, thereby enhancing the bioactivity of TiO₂. GMY 172nm Photomodification Module has advantages such as high energy density, low reaction temperature, short reaction time, and large and uniform coverage area.

172nm High-energy UV Device

The 172nm High-Energy UV Device is utilized for the high-energy decomposition and cleaning of organic particles on the surface of metal materials or silicon-based materials to enhance the performance of semiconductors or batteries. This machine uses high-energy 172nm UV photons to break the chemical bonds of organic molecules, decomposing them into smaller molecules or atoms. Concurrently, 172nm UV photons react with oxygen in the air to form reactive oxygen and ozone, which further decompose to produce more reactive oxygen. These reactive oxygen molecules react with the decomposed organic molecules through oxidation, creating oxides that volatilize, thus completing the surface cleaning. The 172nm high-energy photo-cleaning machine can efficiently remove surface organic contaminants without causing damage to the substrate surface, achieving non-destructive cleaning.
In addition, by precisely controlling the intensity, 172nm excimer light can also complete nano-level modification of the substrate surface and material's surface curing.

Why Choose GMY？

Leveraging over two decades of expertise in the development and manufacturing of lighting technology, GMY specializes in the custom development of 172nm excimer lamps. Providing high-value, tailored solutions for diverse OEM/ODM requirements, we are your premier partner in the domain of high-end lighting technology application customization.

Cutting-edge Technology

GMY employs state-of-the-art excimer technology, delivering highly efficient and accurate light energy output.

Stable and Reliable Quality

Possessing a range of quality certifications, we guarantee the stability and reliability of our products.

Customized Design

We offer customized lamp specifications, including power, length, and diameter, to perfectly match your existing or new equipment needs.

Enhanced Market Presence

With high-performance products, GMY boosts your production capabilities and product excellence, bolstering your market presence.

Free Consultation and Customized Solutions

For any inquiries or to request additional information and support, please fill out the form below.
Our team will get in touch with you in the best possible way.

We value your privacy. We never send you any spam or pass your information to 3rd parties.
